| Brand Name : | Sintec Optronics |
| Certification : | |
| Delivery Time : | Stock |
| Payment Terms : | T/T via bank |
| Model Number : | SMR Series |
| Price : | |
E-fiber series ultrafast lasers integrate the latest femtosecond laser technology. The stable output of 1560 nm femtosecond pulse laser is realized by using high-performance erbium-doped fiber as working medium and high-precision dispersion compensation technology. The output laser pulse has the characteristics of extremely narrow duration and high pulse peak power. The laser is a turnkey product with long-term stable operation and maintenance free. It can be widely used in the research fields of optical frequency comb, supercontinuum, terahertz and so on. Specific combination of pulse duration, repetition rate and average power is customizable.
Features
Applications
| Parameters | Unit | Typical Value | Remarks | ||
| Center Wavelength | nm | 1560±10 | |||
| Spectrum Width | nm | 20 | 60 | ||
| Pulse Duration | fs | 50/100/200/500 | Customizable | ||
| Average Power | mW | 1~120 | Customizable | ||
| Power Instability | - | < ±1% | |||
| Repetition Rate | MHz | 80 | |||
| Repetition Rate Instability | Hz | < 100 | |||
| Pulse Energy | nJ | >1 | |||
| Polarization | - | Linear | Aligned to Slow Axis | ||
| Fiber Type | - | PM Fiber 0.5m | PM Fiber 2m | ||
| Fiber connector | - | FC/APC | |||
| Worm Up time | min | < 1 | |||
| General Parameters | Benchtop | Module |
| Control function | Push Button in Front Panel | RS232 Serial Port |
| Synchronous electrical signal port | SMA | SMA |
| Power Supply | AC100~240V, <30W | DC5V, <20W |
| Dimensions(mm) | 260(W)×280(D)×120(H) | 200(W)×121(D)×65(H) |
| Operation Temperature | 5 ~ 35°C | |
| Operation Humidity | 0~70% | |
| Ordering Information/Product Code | ||||||
| SMR-FSPL | WL(nm) | Pulse Duration(fs) | Power(mW) | Freq (MHz) | Fiber | Packaging |
| 1560 | 50/100/200/ 500 | 10/50/100 | 80/100 | SM PM | B=Benchtop M=Module | |
E-fiber series ultrafast lasers integrate the latest femtosecond laser technology. The stable output of 1560 nm femtosecond pulse laser is realized by using high-performance erbium-doped fiber as working medium and high-precision dispersion compensation technology. The average power can be 1 Watt. The laser is a turnkey product with long-term stable operation and maintenance free. It can be widely used in the research fields of optical frequency comb, supercontinuum, terahertz and so on. Specific combination of pulse duration, repetition rate and average power is customizable.
Features
Applications
| Parameters | Unit | Typical Value | Remarks |
| Center Wavelength | nm | 1560±10 | |
| Pulse Duration | fs | ≤120 | Customizable |
| Average Power | W | 1 | Customizable |
| Power Instability | - | < ±1% | 24h@25°C |
| Repetition Rate | MHz | 80~100 | Customizable |
| Pulse Energy | nJ | >10 | |
| Polarization | - | Line | Vertical |
| DOP | dB | >20dB | |
| Output | - | Free Space | |
| M2 | - | <1.2 | TEM00 |
| Beam Diameter | mm | ≤1.6 | * 1/e2 Waist Diameter |
| Divergence Angle | mrad | <1.5 | |
| Worm Up time | min | < 1 |
| General Parameters | Unit | Value | Remarks |
| Synchronous signal Port | - | SMA | |
| Operation temperature | °C | 5 ～ 45 | |
| Power Supply | - | AC 110~240VAC | Power <40W |
| Dimension | mm | 330(W)×398(D)×112(H) | Benchtop |
| Weight | kg | ≤5 |
| Ordering Information/Product Code | ||||||
| SMR-FSPL | WL(nm) | Pulse Duration(fs) | Power(mW) | Freq (MHz) | Fiber | Packaging |
| 1560 | 120 | 1000 | 80/100 | FS=Free Space | B=Benchtop | |
E-fiber series ultrafast lasers integrate the latest femtosecond laser technology. The stable output of 1560 nm femtosecond pulse laser is realized by using high-performance erbium-doped fiber as working medium and high-precision dispersion compensation technology. The laser has high repetition rate. The laser is a turnkey product with long-term stable operation and maintenance free. It can be widely used in the research fields of optical frequency comb, supercontinuum, terahertz and so on. Specific combination of pulse duration, repetition rate and average power is customizable.
Features
Applications
| Parameters | Unit | Typical Value | Remarks |
| Center Wavelength | nm | 1560±10 | |
| Spectrum Width | nm | 20 | |
| Pulse Duration | fs | 50 ~ 500 | Customizable |
| Average Power | mW | 1 ~ 200 | Customizable |
| Power Instability | - | < ±1% | |
| Repetition Rate | MHz | ≥ 200 | 200MHz~1GHz |
| Repetition Rate Instability | Hz | < 200 | |
| Pulse Energy | nJ | > 1 | |
| Polarization | - | Linear | Aligned to Slow Axis |
| Fiber Type | - | PM fiber, 1m | |
| Fiber connector | - | FC/APC | |
| Worm Up time | min | < 1 |
| General Parameters | Benchtop | Module |
| Control function | Push Button in Front Panel | RS232 Serial Port |
| Synchronous electrical signal port | SMA | SMA |
| Power Supply | AC100~240V, <30W | DC5V, <20W |
| Dimensions(mm) | 260(W)×280(D)×120(H) | 200(W)×121(D)×65(H) |
| Operation Temperature | 5 ~ 35°C | |
| Operation Humidity | 0~70% | |
| Ordering Information/Product Code | ||||||
| SMR-FSPL | WL(nm) | Pulse Duration(fs) | Power(mW) | Freq (MHz) | Fiber | Packaging |
| 1560 | 50/100/200/500 | 10/50/100 | 200/600/1000 | SM PM | B=Benchtop M=Module | |
Specific combination of pulse duration, repetition rate and average power is customizable.
Features
Applications
| Parameters | Unit | Typical Value | Remarks |
| Center Wavelength | nm | 1530~1560 | Customizable |
| Spectrum Width | nm | 0.5~50 | |
| Pulse Duration | ps | 1/10/50/100 | Customizable |
| Average Power | mW | 1~120 | Customizable |
| Power Instability | - | < ±1% | |
| Repetition Rate | MHz | 80 | Customizable |
| Repetition Rate Instability | Hz | < 100 | |
| Pulse Energy | nJ | >1 | |
| Polarization | - | Linear | Aligned to Slow Axis |
| Fiber Type | - | PM Fiber | |
| Fiber connector | - | FC/APC | |
| Worm Up time | min | < 1 |
| General Parameters | Benchtop | Module |
| Control function | Push Button in Front Panel | Push Button in Front Panel |
| Synchronous electrical signal port | SMA | SMA |
| Power Supply | AC100~240V, <30W | DC5V, <20W |
| Dimensions(mm) | 260(W)×280(D)×120(H) | 200(W)×121(D)×65(H)mm |
| Operation Temperature | 5 ~ 35°C | |
| Operation Humidity | 0~70% | |
| Ordering Information/Product Code | ||||||
| SMR-PSPL | WL(nm) | Pulse Duration(fs) | Power(mW) | Freq (MHz) | Fiber | Packaging |
| 1560 | 50/100/200/
500 | 10/50/100 | 80/100 | SM
PM | B= benchtop
M=Module | |
The 780nm is generated by second-harmonic of 1560nm. The laser is a turnkey product with long-term stable operation and maintenance free. It can be widely used in the research fields of optical frequency comb, supercontinuum, terahertz and so on. Specific combination of pulse duration, repetition rate and average power is customizable.
Features
Applications
| Parameters | Unit | Typical Value | Remarks |
| Center Wavelength | nm | 780±10 | |
| Spectrum Width | nm | 20 | |
| Pulse Duration | fs | <100 | Customizable |
| Average Power | mW | >30 | Customizable |
| Power Instability | - | < ±1% | |
| Repetition Rate | MHz | 80 | Customizable |
| Repetition Rate Instability | Hz | < 100 | |
| Pulse Energy | nJ | > 0.4 | |
| Polarization | - | Linear | |
| Fiber Type | - | Free Space | |
| Fiber connector | min | < 1 |
| General Parameters | Benchtop | Module |
| Control function | Push Button in Front Panel | Push Button in Front Panel |
| Synchronous electrical signal port | SMA | SMA |
| Power Supply | AC100~240V, <30W | DC5V, <20W |
| Dimensions(mm) | 260(W)×280(D)×120(H)mm | 200(W)×121(D)×65(H)mm |
| Operation Temperature | 5 ~ 35°C | |
| Operation Humidity | 0~70% | |
| Ordering Information/Product Code | ||||||
| SMR-FSPL | WL (nm) | Pulse Duration(fs) | Power (mW) | Freq (MHz) | Fiber | Packaging |
| 780 | 50/100/200/500 | 1/10/50/ 100 | 80/100 | FS=Free Space | B= benchtop M=Module | |
|
|
