Applications
Holography
Raman spectrum
Precision measurement
Interference lithography
Biomedical/fluorescence
Atomic excitation/absorption
Features
Spectral linewidth <0.00001 nm
Options
Modulation repetition rate up to 1MHz
Frequency stabilized laser optional
Fiber coupled optional
| Wavelength (nm) | Model | Output power (mW) | Features |
| 360 | STC-MSL-FN-360 | 1~50 | |
| 457 | STC-MSL-FN-457 | 1~350 | |
| STC-MSL-RA-457 | 350~1000 | Water cooled | |
| STC-MSL-W-457 | 1000~2000 | Water cooled | |
| 473 | STC-MSL-FN-473 | 1~100 | |
| 515 | STC-MSL-F-515 | 1~20 | |
| 523.5 | STC-MSL-III-523.5 | 1~50 | |
| STC-MSL-FN-523.5 | 50~100 | ||
| 526.5 | STC-MSL-III-526.5 | 1~20 | |
| STC-MSL-FN-526.5 | 20~100 | ||
| 530 | STC-MSL-S-530 | 1~50 | Good seal IP67 |
| STC-MSL-DS-530 | 1~50 | Electronic Integrated | |
| 532 | STC-MSL-III-532 | 1~100 | |
| STC-MSL-S-532 | 1~100 | Good seal IP67 | |
| STC-MSL-DS-532 | 1~100 | Electronic Integrated | |
| STC-MSL-FN-532 | 100~400 | ||
| STC-MSL-F-532 | 400~700 | ||
| STC-MSL-RA-532 | 700~2000 | Water cooled | |
| STC-MSL-R-532 | 2~10 W | Water cooled | |
| STC-MSL-AO-532 | 1~10uJ@1Hz~1kHz, 10ns | Q-switched | |
| 543 | STC-MSL-FN-543 | 1~100 | |
| 556 | STC-MSL-FN-556 | 1~100 | |
| 561 | STC-MSL-FN-561 | 1~80 | |
| 577 | STC-MSL-F-577 | 1~300 | |
| 588 | STC-MSL-FN-588 | 1~200 | |
| 589 | STC-MSL-FN-589 | 1~200 | |
| STC-MSL-RA-589 | 200~500 | Water cooled | |
| 607 | STC-MSL-FN-607 | 1~100 | |
| 639 | STC-MSL-FN-639 | 1~300 | |
| 656.5 | STC-MSL-FN-656.5 | 1~50 | |
| 660 | STC-MSL-FN-660 | 1~20 | |
| 671 | STC-MSL-FN-671 | 1~500 | |
| STC-MSL-R-671 | 500~800 | Water cooled | |
| STC-MSL-RA-671 | 800~1000 | Water cooled | |
| STC-MSL-W-671 | 1000~2500 | Water cooled | |
| 721 | STC-MSL-FN-721 | 1~100 | |
| 914 | STC-MSL-FN-914 | 1~100 | |
| 946 | STC-MSL-FN-946 | 1~50 | |
| 1030 | STC-MSL-FN-1030 | 1~20 | |
| 1047 | STC-MSL-U-1047 | 1~500 | Ultra compact |
| STC-MSL-FN-1047 | 500~800 | ||
| 1053 | STC-MSL-FN-1053 | 1~200 | |
| 1064 | STC-MSL-S-1064 | 1~200 | Good seal IP67 |
| STC-MSL-III-1064 | 200~1000 | ||
| STC-MSL-R-1064 | 1~10 W | Water cooled | |
| STC-MSL-AO-1064 | 1~200uJ@1Hz~1kHz, 25ns | Q-switched | |
| STC-FL-1064-SF | 1~500 | ||
| 1112 | STC-MSL-FN-1112 | 1~20 | |
| 1122 | STC-MSL-FN-1122 | 1~80 | |
| 1313 | STC-MSL-FN-1313 | 1~500 | |
| 1319 | STC-MSL-FN-1319 | 1~50 | |
| 1342 | STC-MSL-III-1342 | 1~200 | |
| STC-MSL-R-1342 | 1~5 W | Water cooled | |
| 1550 | STC-FL-1550-SF | 1~1000 |
Ordering Information: STC-MSL-xx-yy-zz-ss, where xx means series numbers such FN, III, R, FL etc, yy means wavelength in nm, zz means laser power in mW, ss means power stability.
All solid state single longitudinal mode laser at 360nm has the features of ultra compact, long lifetime, low cost and easy operating, which is used in DNA sequencing, flow cytometry, cell sorting, optical instrument, spectrum analysis, interference, measurement, holography, physics experiment, etc.
| Part number | STC-MSL-FN-360-zz-ss |
| Wavelength (nm) | 360±1 |
| Operating mode | CW |
| Output power (mW) | >1, 2, 3, … , 50 |
| Power stability (rms, over 4 hours) | <3%(With TC-01), <5% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% |
| M2 factor | <1.5 |
| Beam diameter at the aperture (1/e2, mm) | <1.5 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | Horizontal±5 degree (Vertical Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 5000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg |
| Dimension/weight (heat sink) | 197(L)×117.5(W) ×57.3(H) mm, 1.6 kg |
| Dimension/weight (heat sink’s driver) | 277(L) ×145(W) ×106(H) mm, 2.6 kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-457-zz-ss | |
| Wavelength (nm) | 457±1 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20, … , 150 | >150, 160, … , 350 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% | <2%, <3%, <5% |
| Transverse mode | TEM00 | Near TEM00 |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <1.2 | |
| Beam diameter at the aperture (1/e2, mm) | <2.0 | |
| Beam divergence, full angle (mrad) | <1.2 | |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 27.4 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg | |
| Part number | STC-MSL-RA-457-zz-ss |
| Wavelength (nm) | 457±1 |
| Output power (mW) | >400, …, 1000 |
| Transverse mode | TEM00 |
| Operating mode | CW |
| Longitudinal mode Single | Single |
| Spectral linewidth (nm) | <0.00001 |
| Power stability (rms, over 4 hours) | <3%, <5% |
| Noise of amplitude (rms, 20Hz~20MHz) | <1% |
| Beam diameter at the aperture (1/e2,mm) | <2.0 |
| Beam divergence, full angle (mrad) | <1.5 |
| M2 factor | <1.2 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Polarization ratio | >100:1 |
| Warm-up time (minutes) | <10 |
| Beam height from base plate (mm) | 51 |
| Operating temperature (℃) | 20~30 |
| Cooled method | Water cooled |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 140.5 (L) × 73 (W) ×46.2 (H) mm, 4kg |
| Dimension/weight (power supply) | 275 (L) ×146(W) ×104 (H) mm, 2.4 kg |
| Dimension/weight (chiller) | 592 (L) ×485W) ×212(H) mm, 15kg |
| Part number | STC-MSL-W457-zz-ss |
| Wavelength (nm) | 457±1 |
| Output power (mW) | >1000, …, 2000 |
| Transverse mode | TEM00 |
| Operating mode | CW |
| Longitudinal mode Single | Single |
| Spectral linewidth (nm) | <0.00001 |
| Power stability (rms, over 4 hours) | <3%, <5% |
| Noise of amplitude (rms, 20Hz~20MHz) | <1% |
| M2 factor | <1.5 |
| Beam divergence, full angle (mrad) | <1.5 |
| Beam diameter at the aperture (1/e2,mm) | <2.0 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Polarization ratio | >100:1 |
| Warm-up time (minutes) | <20 |
| Beam height from base plate (mm) | 54 |
| Cooled method | Water cooled |
| Operating temperature (℃) | 20~25 |
| Power supply (90-264VAC) | STC-PSU-W-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 408(L) ×225(W) ×78(H) mm, 5.7kg |
| Dimension/weight (power supply) | 307(L)×168(W)×123(H) mm, 4.5 kg |
| Dimension/weight (chiller) | 587.5(L)×482(W)×187.5(H) mm, 17 kg |
| Part number | STC-MSL-FN-473-zz-ss | |
| Wavelength (nm) | 473±1 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20, … , 50 | >50, … ,100 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% | <2%, <3%, <5% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <1.2 | |
| Beam diameter at the aperture (1/e2, mm) | <2.5, typical<2.0 | |
| Beam divergence, full angle (mrad) | <1.2 | |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 27.4 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg | |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-F-515-zz-ss |
| Wavelength (nm) | 515±1 |
| Operating mode | CW |
| Output power (mW) | >1, 3, 5, …, 20 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1% |
| M2 factor | <1.5 |
| Beam diameter at the aperture (1/e2, mm) | <3 |
| Beam divergence, full angle (mrad) | <2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 45 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 211(L)×88(W)×74(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg |
| Part number | STC-MSL-III-523.5-zz-ss |
| Wavelength (nm) | 523.5 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 50 |
| Power stability (rms, over 4 hours) | <2%, <3%, <5% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <1.2 |
| Beam divergence, full angle (mrad) | <1.5 |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 24.8 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC or 5VDC) | STC-PSU-III-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 140.5 (L) × 73 (W) ×46.2 (H) mm, 0.6kg |
| Dimension/weight (power supply) | 133 (L) ×130(W) ×62.2 (H) mm, 1.2kg |
| Part number | STC-MSL-FN-523.5-zz-ss |
| Wavelength (nm) | 523.5±1 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 50 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <1.5 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-III-526.5-zz-ss |
| Wavelength (nm) | 526.5 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 20 |
| Power stability (rms, over 4 hours) | <2%, <3%, <5% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <1.2 |
| Beam divergence, full angle (mrad) | <1.5 |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 24.8 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC or 5VDC) | STC-PSU-III-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 140.5 (L) × 73 (W) ×46.2 (H) mm, 0.6kg |
| Dimension/weight (power supply) | 133 (L) ×130(W) ×62.2 (H) mm, 1.2kg |
| Part number | STC-MSL-FN-526.5-zz-ss |
| Wavelength (nm) | 526.5±1 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 100 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <1.5 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | (Harsh condition) | (Normal condition) |
| Wavelength (nm) | 530±1 | |
| Operating mode | CW | |
| Output power (mW) | >1,5,10,20,…,50 | |
| Power stability (rms, over 4 hours) | <1%,<2%,<3% | |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 20Hz~20MHz) | <0.5% | |
| M2factor | <1.2(<1.1 optional) | |
| Beam diameter at the aperture( 1/e2,mm) | 0.7±0.05 | |
| Beam divergence, full angle (mrad) | <1.5 | |
| Polarization ratio | >100:1 Horizontal±5 degree (Vertical Optional) | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Pointing stability Over Temp. (µrad/°C) | <8 | |
| Warm-up time (minutes) | <5 | |
| Beam height from base plate (mm) | 19 | |
| Power Consumption(W) | <30 | |
| Shock Tolerance(6ms) | 7g laterally,15g vertically | |
| IP Rating | IP67 | IP65 |
| Power supply(90-264VAC) | STC-PSU-H-FDA, STC-PSU-A-F | |
| Operating temperature (℃) | 0-60 | 10-35 |
| Max. Heat Dissipation of Head(W) | 10W@50℃ | 4W@25℃ |
| Modulation | Modulation isn’t available. | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 100 (L) ×40 (W) ×40(H) mm, 0.36kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104 (H) mm, 2.3kg (H-FDA) | |
| Model | MSL-DS-530zz-ss |
| Wavelength (nm) | 530±1 |
| Operating mode | CW |
| Output power (mW) | >1,5,10,20,…,50 |
| Power stability (rms, over 4 hours) | <1%,<2%,<3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 20Hz~20MHz) | <0.5% |
| M2 factor | <1.2(<1.1 optional) |
| Beam diameter at the aperture( 1/e2 ,mm) | 0.7±0.05 |
| Beam divergence, full angle (mrad) | <1.5 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Pointing stability Over Temp. (μrad/°C) | <8 |
| Warm-up time (minutes) | <5 |
| Beam height from base plate (mm) | 19 |
| Shock Tolerance(6ms) | 7g laterally,15g vertically |
| Power Supply | 5V DC |
| Operating temperature (℃) | 10-35 |
| Modulation | Modulation isn’t available. |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight | 100 (L) ×60 (W) ×40(H) mm, 0.41kg |
| Part number | STC-MSL-III-532-zz-ss |
| Wavelength (nm) | 532±2 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 100 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <0.5% |
| M2factor | <1.2(<1.1 optional) |
| Beam diameter at the aperture (1/e2, mm) | <1.5 |
| Beam divergence, full angle (mrad) | <1.2 |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 24.8 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-III-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 140.5 (L) × 73 (W) ×46.2 (H) mm, 0.6kg |
| Dimension/weight (power supply) | 133 (L) ×130(W) ×62.2 (H) mm, 1.2kg |
| Model | (Harsh condition) | MSL-S-532-B-zz-ss(Normal condition) |
| Wavelength (nm) | 532±2 | |
| Operating mode | CW | |
| Output power (mW) | >1,5,10,20,…,100 | |
| Power stability (rms, over 4 hours) | <1%,<3%,<5% | |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 20Hz~20MHz) | <0.5% | |
| M2 factor | <1.2 | |
| Beam diameter at the aperture( 1/e2 ,mm) | 0.7±0.05 | |
| Beam divergence, full angle (mrad) | <1.5 | |
| Polarization ratio | >100:1 Horizontal±5 degree (Vertical Optional) | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Pointing stability Over Temp. (μrad/°C) | <8 | |
| Warm-up time (minutes) | <5 | |
| Beam height from base plate (mm) | 19 | |
| Power Consumption(W) | <30 | |
| Shock Tolerance(6ms) | 7g laterally,15g vertically | |
| IP Rating | IP67 | IP65 |
| Power supply(90-264VAC) | STC-PSU-H-FDA | STC-PSU-A-FP |
| Operating temperature (℃) | 0-60 | 10-35 |
| Max. Heat Dissipation of Head(W) | 10W@50℃ | 4W@25℃ |
| Modulation | Modulation isn’t available. | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 100 (L) ×40 (W) ×40(H) mm, 0.36kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104 (H) mm, 2.3kg (H-FDA) | |
| Part number | STC-MSL-DS-532-zz-ss |
| Wavelength (nm) | 532±1 |
| Operating mode | CW |
| Output power before fiber (mW) | >1,5,10,20,…,100 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 20Hz~20MHz) | <0.5% |
| M2 factor | <1.2(<1.1 optional) |
| Beam diameter at the aperture( 1/e2 ,mm) | 0.7±0.05 |
| Beam divergence, full angle (mrad) | <1.5 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Pointing stability Over Temp. (μrad/°C) | <8 |
| Warm-up time (minutes) | <5 |
| Beam height from base plate (mm) | 19 |
| Power Consumption(W) | <6 |
| Fiber | Multimode/ Single Mode |
| Shock Tolerance(6ms) | 7g laterally,15g vertically |
| Power Supply | 5V DC (Photoelectric integrated) |
| Operating temperature (℃) | 10-35 |
| Storage temperature (℃) | 5-50 |
| Modulation | Modulation isn’t available. |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight | 100 (L) ×60 (W) ×40(H) mm, 0.41kg (without fiber) 130.5(L) × 60(W) ×45(H) mm, 0.5kg (with MM fiber) 139(L) × 60(W) ×46(H) mm, 0.52kg (with SM fiber) |
| Part number | STC-MSL-FN-532-zz-ss | |
| Wavelength (nm) | 532±1 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20, … , 300 | >300, …, 400 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% | <2%, <3% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <0.5% | |
| M2 factor | <1.2(<1.1 optional) | |
| Beam diameter at the aperture (1/e2, mm) | <1.5 | |
| Beam divergence, full angle (mrad) | <1.2 | |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 27.4 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg | |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-F-532-zz-ss | |
| Wavelength (nm) | 532±1 | |
| Operating mode | CW | |
| Output power (mW) | >400, 600, … , 500 | 500, … , 700 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3%, <5% | <2%, <3%, <5% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <1.5 | |
| Beam diameter at the aperture (1/e2, mm) | <2.5 | |
| Beam divergence, full angle (mrad) | <1.2 | |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 45 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 211(L)×88(W)×74(H) mm, 2.0 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg | |
| Part number | STC-MSL-RA-532-zz-ss |
| Wavelength (nm) | 532±1 |
| Operating mode | CW |
| Wavelength (nm) | 532±1 |
| Operating mode | CW |
| Output power (mW) | >700, 800, 900, ……2000 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1% |
| Beam diameter at the aperture (1/e2, mm) | <2 |
| Beam divergence, full angle (mrad) | <1.2 |
| M2 factor | <1.2 |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 51 |
| Operating temperature (℃) | 20~30 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 140.5 (L) × 73 (W) ×46.2 (H) mm, 4kg |
| Dimension/weight (power supply) | 275 (L) ×146(W) ×104 (H) mm, 2.4 kg |
| Dimension/weight (chiller) | 592 (L) ×485W) ×212(H) mm, 15kg |
| Part number | STC-MSL-R-532-zz-ss |
| Operating mode | CW |
| Output power (mW) | >700, 800, ..., 10000 |
| Power stability (rms, over 4 hours) | <1%,<2%, <3%, <5% |
| Transverse mode | TEM00 |
| Longitudinal mode Single | Single |
| Noise of amplitude (rms, 20Hz~20MHz) | <1% |
| Polarization ratio | >100:1 |
| M2 factor | <1.2 |
| Beam divergence, full angle (mrad) | <1.5 |
| Beam diameter at the aperture (1/e2,mm) | <1.5 |
| Spectral linewidth (nm) | <0.00001 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 59 |
| Warm-up time (minutes) | <20 |
| Cooled method | Water cooled |
| Operating temperature (℃) | 20~25 |
| Power supply (90-264VAC) | STC-PSU-W-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 432(L) ×218(W) ×82(H) mm, 9kg |
| Dimension/weight (power supply) | 307(L)×168(W)×123(H) mm, 4.5 kg |
| Dimension/weight (chiller) | 587.5(L)×482(W)×187.5(H) mm, 17 kg |
| Part number | STC-MSL-AO-532-zz-ss |
| Wavelength (nm) | 532±1 |
| Operating mode | Acousto-Optic Q-switched |
| Single pulse energy (μJ) | 1~100 |
| Longitudinal mode | Single |
| Pulse duration (ns) | <25 |
| Peak power (kW) | 1~4 |
| Rep. rate (Hz) | 1~1000 |
| Polarization ratio | >100:1 |
| Ave power stability (over 4 hours) | <3%, <5% |
| Beam divergence, full angle (mrad) | <2 |
| Beam diameter at the aperture (1/e2,mm) | ~2 |
| Beam height from base plate (mm) | 59 |
| Warm-up time (minutes) | <20 |
| Cooled method | Water Cooled |
| Operating temperature (℃) | 20~30 |
| Power supply (90-264VAC) | STC-PSU-AOM(3U) |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 432(L) ×218(W) ×82(H) mm, 9kg |
| Dimension/weight (power supply) | 483.5 (L) ×454 (W) ×147.5 (H) mm, 8.3 kg |
| Dimension/weight (chiller) | 587.5(L)×482(W)×187.5(H) mm, 17 kg |
n
| Part number | STC-MSL-FN-543-zz-ss |
| Wavelength (nm) | 543±1 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, … , 20 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <1.5 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-556-zz-ss |
| Wavelength (nm) | 556±1 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 100 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3%, <5% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <2.0 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-561-zz-ss | |
| Wavelength (nm) | 561±1 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20,, | 150 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3%, <5% | |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <1.2 | |
| Beam diameter at the aperture (1/e2, mm) | <2.0 | |
| Beam divergence, full angle (mrad) | <1.2 | |
| Polarization ratio | >100:1,Vertical±5 degree (Horizontal Optional) | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 27.4 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3 kg | |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-F-577-zz-ss | |
| Central wavelength (nm) | 577±2 | |
| Operating mode | CW | |
| Output power (mW) | >10, 20, 50, …, 200 | >200, …, 300 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% | <2%, <3%, <5% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <1.5 | |
| Beam diameter at the aperture (1/e2,mm) | ~2.5 | |
| Beam divergence, full angle (mrad) | <1.5 | |
| Beam height from base plate (mm) | 45 | |
| Polarization ratio | >100:1 Horizontal±5 degree (Vertical Optional) | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Operating temperature (℃) | 10~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty period | 1 year | |
| Dimension/weight (laser head) | 211(L)×88(W)×74(H) mm, 1.6 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg | |
| Part number | STC-MSL-FN-588-zz-ss |
| Wavelength (nm) | 588±2 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 200 |
| Power stability (rms, over 4 hours) | <3%, <5%, <10% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <2.5 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Horizontal±5 degree (Vertical Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 211(L)×88(W)×74(H) mm, 1.36 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
| Part number | STC-MSL-F-589-zz-ss |
| Wavelength | 589±1 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20,… 200 |
| Power stability (rms, over 4 hours) | <3%, <5%, <10% |
| Transverse mode | Near TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <2.5 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Horizontal±5 degree (Vertical Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 45 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 211(L)×88(W)×74(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
| Part number | STC-MSL-RA-589-zz-ss |
| Wavelength (nm) | 589±1 |
| Output power (mW) | >1, 10, …, 500 |
| Transverse mode | TEM00 |
| Operating mode | CW |
| Longitudinal mode Single | Single |
| Spectral linewidth (nm) | <0.00001 |
| Power stability (rms, over 4 hours) | <3%, <5% |
| Noise of amplitude (rms, 20Hz~20MHz) | <1% |
| Beam diameter at the aperture (1/e2,mm) | <2.0 |
| Beam divergence, full angle (mrad) | <1.5 |
| M2 factor | <1.2 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Polarization ratio | >100:1 |
| Warm-up time (minutes) | <10 |
| Beam height from base plate (mm) | 51 |
| Operating temperature (℃) | 20~30 |
| Cooled method | Water cooled |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 140.5 (L) × 73 (W) ×46.2 (H) mm, 4kg |
| Dimension/weight (power supply) | 275 (L) ×146(W) ×104 (H) mm, 2.4 kg |
| Dimension/weight (chiller) | 592 (L) ×485W) ×212(H) mm, 15kg |
| Part number | STC-MSL-FN-607-zz-ss |
| Wavelength (nm) | 607±1 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 100 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <1.5 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-639-zz-ss |
| Wavelength (nm) | 639±1 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … 300 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >40 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% |
| M2 factor | <1.2(<1.1 optional) |
| Beam diameter at the aperture (1/e2, mm) | <1.5 |
| Beam divergence, full angle (mrad) | <1.5 |
| Polarization ratio | >100:1, Horizontal±5 degree (Vertical Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up ( mrad/℃) | 6 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-656.5-zz-ss |
| Wavelength (nm) | 656.5±1 |
| Output power (mW) | >1, 5, 10, 20, … , 50 |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Operating mode | CW |
| Power stability (rms, over 4 hours) | <1%, <3%, <5% |
| Warm-up time (minutes) | <10 |
| M2 factor | <1. 2 |
| Beam divergence, full angle (mrad) | <1. 2 |
| Beam diameter at the aperture (mm) | ~2. 0 |
| Beam height from base plate (mm) | 27.4 |
| Polarization ratio | >100:1, Vertical±5 degree |
| Spectral linewidth (nm) | <0.00001 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Noise of amplitude (rms, 20Hz~20MHz) | <0. 5% |
| Coherent length (m) | >50 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Modulation | Modulation isn’t available. |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-660-zz-ss |
| Wavelength (nm) | 660±1 |
| Operating mode | CW |
| Output power (mW) | >1, 2, 3, … , 20 |
| Power stability (rms, over 4 hours) | <3%, <5% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <2.0 |
| Beam divergence, full angle (mrad) | <1.2 |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-671-zz-ss | |
| Wavelength (nm) | 671±1 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20, … , 300 | >300, … , 500 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% | <2%, <3% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <1.2(<1.1 optional) | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <2.0, typical<1.5 | |
| Beam divergence, full angle (mrad) | <1.2 | |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 27.4 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg | |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-R-671-zz-ss |
| Wavelength (nm) | 671±1 |
| Operating mode | CW |
| Output power (mW) | >500, 600, ......, 800 |
| Power stability (rms, over 4 hours) | <3%, <5%, <10% |
| Transverse mode | TEM00 |
| Longitudinal mode Single | Single |
| Noise of amplitude (rms, 20Hz~20MHz) | <1% |
| Polarization ratio | >100:1 |
| M2 factor | <1.5 |
| Beam divergence, full angle (mrad) | <1.5 |
| Beam diameter at the aperture (1/e2,mm) | ~1.5 |
| Spectral linewidth (nm) | <0.00001 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 59 |
| Warm-up time (minutes) | <20 |
| Cooled method | Water cooled |
| Operating temperature (℃) | 20~25 |
| Power supply (90-264VAC) | STC-PSU-W-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 432(L) ×218(W) ×82(H) mm, 9kg |
| Dimension/weight (power supply) | 307(L)×168(W)×123(H) mm, 4.5 kg |
| Dimension/weight (chiller) | 587.5(L)×482(W)×187.5(H) mm, 17 kg |
| Part number | STC-MSL-RA-671-zz-ss |
| Wavelength (nm) | 671±1 |
| Output power (mW) | >1, 10, …, 1000 |
| Transverse mode | TEM00 |
| Operating mode | CW |
| Longitudinal mode Single | Single |
| Spectral linewidth (nm) | <0.00001 |
| Power stability (rms, over 4 hours) | <3%, <5% |
| Noise of amplitude (rms, 20Hz~20MHz) | <1% |
| Beam diameter at the aperture (1/e2,mm) | <2.0 |
| Beam divergence, full angle (mrad) | <1.5 |
| M2 factor | <1.2 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Polarization ratio | >100:1 |
| Warm-up time (minutes) | <10 |
| Beam height from base plate (mm) | 51 |
| Operating temperature (℃) | 20~30 |
| Cooled method | Water cooled |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 140.5 (L) × 73 (W) ×46.2 (H) mm, 4kg |
| Dimension/weight (power supply) | 275 (L) ×146(W) ×104 (H) mm, 2.4 kg |
| Dimension/weight (chiller) | 592 (L) ×485W) ×212(H) mm, 15kg |
| Part number | STC-MSL-W-671-zz-ss |
| Wavelength (nm) | 671±1 |
| Output power (mW) | >800, 1000, …, 2500 |
| Transverse mode | TEM00 |
| Operating mode | CW |
| Longitudinal mode Single | Single |
| Spectral linewidth (nm) | <0.00001 |
| Power stability (rms, over 4 hours) | <3%, <5% |
| Noise of amplitude (rms, 20Hz~20MHz) | <1% |
| M2 factor | <1.5 |
| Beam divergence, full angle (mrad) | <1.5 |
| Beam diameter at the aperture (1/e2,mm) | <3.0 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Polarization ratio | >100:1 |
| Warm-up time (minutes) | <20 |
| Beam height from base plate (mm) | 58 |
| Cooled method | Water cooled |
| Operating temperature (℃) | 20~25 |
| Power supply (90-264VAC) | STC-PSU-W-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 408(L) ×225(W) ×78(H) mm, 5.7kg |
| Dimension/weight (power supply) | 307(L)×168(W)×123(H) mm, 4.5 kg |
| Dimension/weight (chiller) | 587.5(L)×482(W)×187.5(H) mm, 17 kg |
| Part number | STC-MSL-FN-721-zz-ss | |
| Wavelength (nm) | 721±1 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20, … , 50 | >50, … , 100 |
| Power stability (rms, over 4 hours) | <3%, <5% | <3%, <5%, <10% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <1.2 | |
| Beam diameter at the aperture (1/e2, mm) | <1.5 | |
| Beam divergence, full angle (mrad) | <1.2 | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 27.4 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg | |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-914-zz-ss |
| Wavelength (nm) | 914±1 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 100 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <1.5 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-946-zz-ss |
| Wavelength (nm) | 946±1 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 100 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | <2.0 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-1030-zz-ss |
| Wavelength (nm) | 1030±2 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, … , 20 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | ~2 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-U-1047-zz-ss | |
| Central wavelength (nm) | 1047 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20, … , 200 | >200, … , 500 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3%, <5% | <2%, <3%, <5% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <1.2 | |
| Beam diameter at the aperture (1/e2, mm) | 0.70±0.05 | |
| Beam divergence (mrad) | <1.5 | |
| Polarization Ratio | >100:1, Horizontal±5 degree | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 27.4 | |
| Laser head consumption(W) | 15 (typical) , <25 (40℃) | |
| Max. Laser Head Base plate Temp (°C) | 50 | |
| Operating Temperature (°C) | 10-40 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 136(L)×60(W) ×50(H) mm, 1.5 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg | |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-1047-zz-ss | |
| Wavelength (nm) | 1047±1 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20, … , 300 | >300, … , 800 |
| Power stability (rms, over 4 hours) | <2%, <3%, <5% | <3%, <5% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <1.5 | |
| Beam diameter at the aperture (1/e2, mm) | <2.0 | |
| Beam divergence, full angle (mrad) | <1.5 | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 27.4 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg | |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-1053-zz-ss | |
| Wavelength (nm) | 1053±1 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20, … , 100 | >100, … , 200 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3%, <5% | <2%, <3%, <5% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <1.5 | |
| Beam diameter at the aperture (1/e2, mm) | <2.0 | |
| Beam divergence, full angle (mrad) | <1.5 | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 27.4 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg | |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-S-1064-A (Harsh condition) | STC-MSL-S-1064-B (Normal condition) | |||
| Central wavelength (nm) | 1064±1 | ||||
| Operating mode | CW | ||||
| Output power (mW) | >1,5,10,20,…,100 | >100,…,200 | >1,5,10,20,…,100 | >100,…,200 | |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% | <2%, <3% | <1%, <2%, <3% | <2%, <3% | |
| Transverse mode | TEM00 | ||||
| Longitudinal mode | Single | ||||
| Spectral linewidth (nm) | <0.00001 | ||||
| Coherent length (m) | >50 | ||||
| M2 factor | <1.2 | ||||
| Beam diameter at the aperture( 1/e2 ,mm) | 1.00±0.05 | ||||
| Beam divergence, full angle (mrad) | <1.7 | ||||
| Pointing stability after warm-up (mrad) | <0.05 | ||||
| Pointing stability Over Temp. (μrad/°C) | <8 | ||||
| Warm-up time (minutes) | <5 | ||||
| Beam height from base plate (mm) | 19 | ||||
| Power Consumption(W) | <40 | ||||
| Shock Tolerance(6ms) | 7g laterally,15g vertically | ||||
| IP Rating | IP67 | IP65 | |||
| Power supply(90-264VAC) | STC-PSU-H-FDA | STC-PSU-A-F | |||
| Operating temperature (℃) | 0-60 | 10-35 | |||
| Max. Heat Dissipation of Head(W) | 10W@50℃ | 4W@25℃ | |||
| Modulation | Modulation isn’t available. | ||||
| Expected lifetime (hours) | 10000 | ||||
| Warranty | 1 year | ||||
| Dimension/weight (laser head) | 100 (L) ×40 (W) ×40(H) mm, 0.36kg | ||||
| Dimension/weight (power supply) | 236(L) ×145(W) ×104 (H) mm, 2.3kg (H-FDA) | ||||
| Part number | STC-MSL-III-1064-zz-ss | ||
| Wavelength (nm) | 1064±1 | ||
| Operating mode | CW | ||
| Output power (mW) | >1, 5, 10, 20, … , 500 | >500, … , 1000 | |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% | 2%, <3% | |
| Transverse mode | TEM00 | ||
| Longitudinal mode | Single | ||
| Spectral linewidth (nm) | <0.00001 | ||
| Coherent length (m) | >50 | ||
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | ||
| M2 factor | <1.5(<1.2 optional) | <1.5 | |
| Beam diameter at the aperture (1/e2, mm) | <2.0 | ||
| Beam divergence, full angle (mrad) | <1.5 | ||
| Warm-up time (minutes) | <10 | ||
| Pointing stability after warm-up (mrad) | <0.05 | ||
| Beam height from base plate (mm) | 24.8 | ||
| Operating temperature (℃) | 15~35 | ||
| Power supply (90-264VAC) | STC-PSU-III-FDA | ||
| Expected lifetime (hours) | 10000 | ||
| Warranty | 1 year | ||
| Dimension/weight (laser head) | 140.5 (L) × 73 (W) ×46.2 (H) mm, 0.6kg | ||
| Dimension/weight (power supply) | 133 (L) ×130(W) ×62.2 (H) mm, 1.2kg | ||
| Part number | STC-MSL-R-1064-zz-ss |
| Wavelength (nm) | 1064±1 |
| Operating mode | CW |
| Output power (W) | >1, 2, ..., 10 |
| Power stability (rms, over 4 hours) | <1%, <2%,<3%, <5% |
| Transverse mode | TEM00 |
| Longitudinal mode Single | Single |
| Noise of amplitude (rms, 20Hz~20MHz) | <0.5% |
| Polarization ratio | >100:1 |
| M2 factor | <1.5 |
| Beam divergence, full angle (mrad) | <1.5 |
| Beam diameter at the aperture (1/e2,mm) | ~1.5 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Spectral linewidth (nm) | <0.00001 |
| Beam height from base plate (mm) | 59 |
| Warm-up time (minutes) | <20 |
| Cooled method | Water cooled |
| Operating temperature (℃) | 20~30 |
| Power supply (90-264VAC) | STC-PSU-W-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 432(L) ×218(W) ×82(H) mm, 9kg |
| Dimension/weight (power supply) | 307(L)×168(W)×123(H) mm, 4.5 kg |
| Dimension/weight (chiller) | 587.5(L)×482(W)×187.5(H) mm, 17 kg |
| Part number | STC-MSL-AO-1064-zz-ss |
| Wavelength (nm) | 1064±1 |
| Operating mode | Acousto-Optic Q-switched |
| Single pulse energy (μJ) | 1~200 |
| Longitudinal mode | Single |
| Pulse duration (ns) | <25 |
| Peak power (kW) | 1~8 |
| Rep. rate (Hz) | 1~1000 |
| Polarization ratio | >100:1 |
| Ave power stability (over 4 hours) | <3%, <5% |
| Beam divergence, full angle (mrad) | <2 |
| Beam diameter at the aperture (1/e2,mm) | ~2 |
| Beam height from base plate (mm) | 59 |
| Warm-up time (minutes) | <20 |
| Cooled method | Water Cooled |
| Operating temperature (℃) | 20~30 |
| Power supply (90-264VAC) | STC-PSU-AOM(3U) |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 432(L) ×218(W) ×82(H) mm, 9kg |
| Dimension/weight (power supply) | 483.5 (L) ×454 (W) ×147.5 (H) mm, 8.3 kg |
| Dimension/weight (chiller) | 587.5(L)×482(W)×187.5(H) mm, 17 kg |
| Part number | STC-FL-1064-SF-zz-ss |
| Wavelength (nm) | 1064±1 |
| Operating mode | CW |
| Output power (mW) | 10, 100, 500 |
| Power stability (rms, over 4 hours) | <1%, <2% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (KHz) | <100 |
| Frequency shift (MHz) | <10@1hour |
| M2 factor | <1.2 |
| Beam Delivery Optics | FC/APC |
| Polarization ratio(dB) | >15 |
| Warm-up time (minutes) | <30 |
| Operating temperature (℃) | 15~30 |
| Power supply (V DC) | 12 |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Options | RS 232 interface, PZT tuning |
| Dimension/weight | 420(L)×380(W) ×49(H)mm, 7 kg |
| Part number | STC-MSL-FN-1112-zz-ss |
| Wavelength (nm) | 1112±3 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, … , 20 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | ~2 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-1122-zz-ss |
| Wavelength (nm) | 1122±3 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 80 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1% |
| M2 factor | <1.2 |
| Beam diameter at the aperture (1/e2, mm) | ~2 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-1313-zz-ss | |
| Wavelength (nm) | 1313±1 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20, … , 200 | >200, … , 500 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3%, <5% | <2%, <3%, <5% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <2.0 | |
| Beam diameter at the aperture (1/e2, mm) | <2.0 | |
| Beam divergence, full angle (mrad) | <1.5 | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 27.4 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-H-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg | |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg | |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-FN-1319-zz-ss |
| Wavelength (nm) | 1319±1 |
| Operating mode | CW |
| Output power (mW) | >1, 5, 10, 20, … , 50 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3%, <5% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% |
| M2 factor | <2.0 |
| Beam diameter at the aperture (1/e2, mm) | <2.0 |
| Beam divergence, full angle (mrad) | <1.5 |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature (℃) | 15~35 |
| Power supply (90-264VAC) | STC-PSU-H-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
| Dimension/weight (laser head) | 197(L)×70(W)×50(H) mm, 2.0 kg |
| Dimension/weight (power supply) | 236(L) ×145(W) ×104(H) mm, 2.3kg |
Note: The laser head needs to be used on a heat sink with good heat dissipation.
| Part number | STC-MSL-III-1342-zz-ss | |
| Wavelength (nm) | 1342±1 | |
| Operating mode | CW | |
| Output power (mW) | >1, 5, 10, 20, … , 100 | >100, … , 200 |
| Power stability (rms, over 4 hours) | <1%, <2%, <3%, <5% | <2%, <3%, <5% |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (nm) | <0.00001 | |
| Coherent length (m) | >50 | |
| Noise of amplitude (rms, 1Hz~20MHz) | <1%, typical<0.5% | |
| M2 factor | <2.0 | |
| Beam diameter at the aperture (1/e2, mm) | <2.0 | |
| Beam divergence, full angle (mrad) | <1.5 | |
| Polarization ratio | >100:1, Horizontal±5 degree (Vertical Optional) | |
| Warm-up time (minutes) | <10 | |
| Pointing stability after warm-up (mrad) | <0.05 | |
| Beam height from base plate (mm) | 24.8 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (90-264VAC) | STC-PSU-III-FDA | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Dimension/weight (laser head) | 140.5 (L) × 73 (W) ×46.2 (H) mm, 0.6kg | |
| Dimension/weight (power supply) | 133 (L) ×130(W) ×62.2 (H) mm, 1.2kg | |
| Part number | STC-MSL-R-1342-zz-ss |
| Wavelength (nm) | 1342±1 |
| Operating mode | CW |
| Output power (W) | >1, 2, ..., 5 |
| Power stability (rms, over 4 hours) | <1%,<2%, <3%, <5% |
| Transverse mode | TEM00 |
| Longitudinal mode Single | Single |
| Noise of amplitude (rms, 20Hz~20MHz) | <0.5% |
| Polarization ratio | >100:1 |
| M2 factor | <1.5 |
| Beam divergence, full angle (mrad) | <1.5 |
| Beam diameter at the aperture (1/e2,mm) | ~1.5 |
| Spectral linewidth (nm) | <0.00001 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 59 |
| Warm-up time (minutes) | <20 |
| Cooled method | Water cooled |
| Operating temperature (℃) | 20~30 |
| Power supply (90-264VAC) | STC-PSU-W-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
| Dimension/weight (laser head) | 432(L) ×218(W) ×82(H) mm, 9kg |
| Dimension/weight (power supply) | 307(L)×168(W)×123(H) mm, 4.5 kg |
| Dimension/weight (chiller) | 587.5(L)×482(W)×187.5(H) mm, 17 kg |
| Part number | STC-FL-1550-SF-II-zz-ss | STC-FL-1550-SF-I-zz-ss |
| Wavelength (nm) | 1550±1 | |
| Operating mode | CW | |
| Output power (mW) | 1~500 | 1~1000 |
| Power stability (rms, over 4 hours) | <1%, <2% | |
| Transverse mode | TEM00 | |
| Longitudinal mode | Single | |
| Spectral linewidth (kHz) | <100 | <2000 |
| M2 factor | <1.2 | |
| Beam Delivery Optics | FC/APC | |
| Polarization ratio(dB) | >15 | |
| Warm-up time (minutes) | <15 | |
| Beam height from base plate (mm) | 58 | |
| Operating temperature (℃) | 15~35 | |
| Power supply (V DC) | 12 | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
| Options | RS 232 interface | |
| Dimension/weight | 420(L)×380(W) ×49(H)mm, 7 kg | 264(L)×214(W) ×75(H), 3 kg |
The DPSS CW deep UV laser series SFQCW-266, diode pumped continuous wave solid state laser, comes with a resonant frequency conversion stage, emitting a fixed wavelength of 266nm. The laser head is contained in a sealed aluminium housing, which allows operation in a wide range of environmental conditions. Heat removal from the laser head is done by air convection.
The SFQCW-266 plug & play laser comes with a control unit, allowing either push button control or remote control operation via serial (RS232 & USB) interface. The lasers offer excellent beam quality with an M2 below 1.3 , beam divergence below 0.8mrad (full angle), low intensity noise below 0.5% rms (100 kHz-10MHz) and a good power stability (<1% in 8 hours). These CW laser units are the proper tools for industrial use and intensive R&D applications as Raman Spectroscopy, Wafer inspection and Photoluminescence where a long coherence length is required.
Features:
Single frequency
Low noise
TEM00
Long coherence length of 1000m
High beam quality M2 < 1.3
Small footprint (rugged and compact)
Conduction cooling
User friendly
Line width < 300 kHz
Applications:
Raman
Inspections
Analytics
DVD mastering
| Model | SFQCW-266-10 | SFQCW-266-50 | SFQCW-266-100 | SFQCW-266-200 |
| Nominal output power | 10mW | 50mW | 100mW | 200mW |
| Output power stability | 2-12mW | 5-55mW | 10-110mW | 20-220mW |
| Wavelength | 266nm | |||
| Linewidth | <300kHz | |||
| Coherence length | >1000m | |||
| Beam quality factor M2 | <1.3 | |||
| Polarization | Vertical, >100:1 | |||
| Beam diameter | 0.55mm±20% | |||
| Beam divergence(full angle) | <0.8mrad | |||
| Beam positioning stability1 | <3urad/K | |||
| Static alignment tolerance4 | Position<±0.25mm, Angle<±2.5mrad | |||
| Power stability1 (8h, 1s average) | <1% rms | |||
| Noise (100kHz-10MHz) | <0.5% rms | |||
| Line voltage | 90V – 250VAC | |||
| Power consumption mean (Max) | 100W (200W) | |||
| Communication interface | USB/RS232 | |||
| Safety equipment | Key switch, interlock | |||
| Dimensions control unit | 363x325x115 mm | |||
| Weight control unit | 5.3kg | |||
| Dimensions laser head | 379x270x91 mm | 379(+50)5x270x91 mm | ||
| Weight laser head | 17kg | |||
| Operating temperature | 20-35°C non-condensing | |||
| Warm-up time (cold start) | <15minutes | |||
| Purge Interface for Exit Window | CDA 0.5LPM, ~2%rH, particle filter 0.01μm | |||
Notes:
After 30 minutes warm-up in the temperature range 20 - 35°C, temperature change < 1°C/hour.
2. The exit window is equipped with the Manual Window Shifter (MWS) in case of external photo contamination.
This laser system is not equipped with the Automatic Crystal Shifter (ACS) due to the lower power densities on all internal optical elements.
Position and angle of static alignment tolerances are specified with regard to laser beam exit.
Length of laser head is +50mm expanding by using purge interface.
|
|
